Being widely appreciated in filtration industry worldwide, Fabricated as per the International standard,high quality,durable,reliable and optional in Single and Multi layer (DLW) weave designs.
Description
The main advantages of the nylon mesh
1.Good surface tension
2.Excellent wear resistance
3.Good absorbent
4.Good alkali resistance
5.Good elasticity
Specification
| Item | Material | Mesh count | Diameter yarn | Mesh opening | Open area | Thickness | Weight | |
| NO | mesh/cm | mesh/inch | microns | microns | % | microns | g/㎡ | |
| JFP30 | PA6 | 30 | 76 | 60*2 | 121 | 40 | 115 | 45 |
| JFP33 | PA6 | 33 | 84 | 60*2 | 181 | 36 | 115 | 50 |
| JFP36 | PA6 | 36 | 90 | 60*2 | 156 | 32 | 115 | 54 |
| JFP39 | PA6 | 39 | 100 | 60*2 | 135 | 28 | 120 | 58 |
| JFP42 | PA6 | 42 | 107 | 60*2 | 116 | 24 | 120 | 62 |
| JFP46 | PA6 | 46 | 120 | 50*2 | 118 | 29 | 105 | 48 |
| JFP50 | PA6 | 50 | 127 | 50*2 | 101 | 25 | 105 | 52 |
| JFP54 | PA6 | 54 | 137 | 40*2 | 99 | 29 | 85 | 36 |
| JFP58 | PA6 | 58 | 147 | 40*2 | 86 | 25 | 87 | 38.5 |
| JPP62 | PA6 | 62 | 157 | 40*2 | 75 | 22 | 88 | 41 |
