The main use of Conveyor belt is discharging, declining transportation or homogenizing the powder or small granular material in quiescent condition. We adopt 100% polyester yarns for Conveyor belt material.
- The max. length per roll: 50 M.
- Width: 0.10 M ~ 2.6 M.
- Thickness: 4~10 MM.
- Max. Operating Temp.: 160 ℃.
- Ultimate Temp.( Instant ): 200 ℃.Our capacity: 500 ㎡/ month.
Description
Polyester Conveyor Belt & Spun Polyester Conveyor Belt
Our company’s spun polyester Conveyor belt has advantages on the performances of tensile strength, air permeability, and high temperature resistance. But filament polyester Conveyor belt is superior to spun polyester Conveyor belt on the above performances. Conveyor belt is also named as air slide fabric, air slide cloth, air slide membrane, air slide canvas, air permeable fabric, canvas cloth, fluidization cloth and fluidizing fabric. However, we are also able to weave fabrics to our customers’ specific demands for air permeability and mechanical strength.
Technical parameter of conveyor belt
| Product Name | Filament Polyester Air Slide Fabric |
Spun Polyester Air Slide Fabric |
|
| Thickness( mm) | 5 | 5 | |
| Gram Weight(gsm) | 3900 | 3600 | |
| Air permeability(L/m2.s) | 85 | 75 | |
| Tensile strength(kg/cm2) | >500 | > 470 | |
| Elongation (Strength:2000 N/2 cm) |
Warp | 2.1% | 2.3% |
| Weft | 1.0% | 1.1% | |
| Max. Operating Temp. | 160 ℃ (320 F) | 160 ℃ (320 F) | |
| Ultimate Temp.(Instant) | 200 ℃ (392 F) | 200 ℃(392 F) | |
| Number of plies | 5 | 5 | |
Ps: Average errors of thickness is +/- 0.3mm , gram weight is +/- 5%, air permeability is +/- 10%
Applications of conveyor belt
- Cement industry: cement bulk cement trucks,boats;
- Mining: alumina,lime,fly ash,phosphate;
- Chemical industry: soda;
- Power: fly ash, desulfurization;
- Food industry: flour.
